Model	Switching frequency	Standby power consumption	Maximum power	MOS withstand voltage	Package form
SC2514Q	65KHZ	<75mW	24W	650V	DIP7
SC2521	65KHZ	<75mW	10W	650V	DIP8
SC2522S	65KHZ	<75mW	12W	650V	SOP8
SC2522T	65KHZ	<75mW	15W	650V	DIP8
SC2524T	65KHZ	<75mW	24W	650V	DIP8
SC2526T	65KHZ	<75mW	24W	650V	DIP8
SC2542	65KHZ	<75mW	12W	650V	SOP8
SC2544	65KHZ	<75mW	18W	650V	SOP8
SC2555	65KHZ	<75mW	18W	650V	SOP8
SC2556	65KHZ	<75mW	24W	650V	SOP8
SC2564	65KHZ	<75mW	24W	650V	SOP8
SC2566	65KHZ	<75mW	24W	650V	SOP8
SC3524	65KHZ	<75mW	24W	650V	SOP7
SC3526	65KHZ	<75mW	24W	650V	DIP8

Model	High voltage start-up	Standby power consumption	Peak Load	OCP	OLP	Package form
SC2581	N	<75mW	N	Y	Y	SOT23-6
SC2582	N	<100mW	N	Y	Y	SOT23-6
SC2583	N	<100mW	N	Y	N	SOT23-6/DIP8/SOP8
SC2584	N	<100mW	N	Y	Y	SOT23-6
SC2560	N	<75mW	N	N	N	SOT23-6
SC2569	N	<300mW	N	N	Y	DIP8/SOP8
SC2585	N	<75mW	N	Y	Y	SOT23-6
SC2585A	N	<75mW	N	Y	Y	SOT23-6
SC2585B	N	<75mW	N	Y	Y	SOT23-6
SC2585C	N	<75mW	N	Y	Y	SOT23-6
SC2585D	N	<75mW	N	Y	Y	SOT23-6
SC2585E	N	<75mW	N	Y	Y	SOT23-6
SC2586	N	<75mW	N	Y	Y	SOT23-6
SC2586H	N	<75mW	N	Y	Y	SOT23-6
SC3105B	N	<75mW	Y	A	A	SOT23-6
SC3105C	N	<75mW	Y	L	L	SOT23-6
SC5105B	Y	<75mW	Y	A	A	SOP8
SC5105C	Y	<75mW	Y	L	L	SOP8
SC5105D	Y	<75mW	Y	A	A	SOP8
SC5105E	Y	<75mW	Y	A	A	SOP8

Model
Duty cycle
OLP BO SS delay Package form
SC3151 50% N Y Y SOP8
SC3152 50% N Y Y SOP8/DIP8
SC3152E 45% N Y N SOP8
SC6313 50% Y Y Y SOP8/DIP8
SC6313B 50% Y Y N SOP8/DIP8
SC6313C 70% Y Y Y SOP8/DIP8

Model	Maximum frequency	Standby power consumption	Maximum power	MOS is pressure-resistant	Package form
SC2662	70KHZ	<75mW	12W	650V	SOP8
SC2663	70KHZ	<75mW	15W	650V	SOP8
SC2664	70KHZ	<75mW	18W	650V	DIP8
SC2664A	70KHZ	<75mW	18W	650V	DIP8
SC2624	70KHZ	<75mW	18W	650	SOP7/DIP8
SC2634	70KHZ	<75mW	18W	650	SOP7/DIP8
SC2635	70KHZ	<75mW	18W	650V	SOP8
SC2685	70KHZ	<75mW	24W	650V	DIP8
SC2672	70KHZ	<75mW	12W	650V	SOP7/DIP8
SC2674	70KHZ	<75mW	24W	650V	SOP7/DIP8

Model Maximum frequency Standby power consumption Maximum frequency Package form
SC2650 90KHZ <75mW 30W SOT23-6
SC2650B 90KHZ <75mW
30W
SOT23-6
SC2670 70KHZ <75mW
30W
SOT23-6

Model
Maximum operating pressure
Working mode
Maximum operating frequency
Package type
SC7600 60V DCM/QR/CCM
200KHZ SOP8
SC7200 200V DCM/QR/CCM 200KHZ
SOP8
MX9901 60V DCM/QR/CCM
100KHZ
SOP8

Model	Maximum operating pressure	Maximum operating frequency	Working mode	Package type
SC743X	40V	150KHZ	DCM/QR	SOP8
SC762X	60V	200KHZ	DCM/QR/CCM	SOP8
SC763X	60V	200KHZ	DCM/QR/CCM	SOP8
SC722X	100V	200KHZ	DCM/QR/CCM	SOP8
SC723X	100V	200KHZ	DCM/QR/CCM	SOP8

- CCM mode
Model
Operating frequency
Current sense mode
Working mode
Package type
SC3654 65KHZ
Average current
CCM SOP8
SC3654H 133KHZ Average current
CCM SOP8

Model	Operating frequency	PWM maximum operating frequency	Package form	Multiplier
SC3805	fpfc=fpwm	95KHZ	SIP9/SSOP10	N
SC3805A	fpfc=fpwm	70KHZ	SIP9/SSOP10	N
SC3805B	fpfc=1/2*fpwm	140KHZ	SIP9/SSOP10	N
SC3806	fpfc=fpwm	External RC settings	DIP16/SOP16	N
SC3806H	fpfc=1/2*fpwm	External RC settings	DIP16/SOP16	N

Model
Maximum duty
Maximum frequency
Dead time
Package form
SC3510 50% 600KHZ
350nS
SOP-16
